Flue gas analyser for heating applications

The ecom-CL2 flue gas analyser is the practical all-in-one solution for fast, precise, standards-compliant flue gas measurement on gas and oil heating systems. This mobile compact device combines robust construction, an integrated thermal high-speed printer and state-of-the-art sensor technology, enabling reliable on-site measurement, documentation and evaluation. Tested in accordance with EN 50379-2 and 1st BImSchV.

O₂

Basis EC Opt. EC

max.

3 Gas options

Order directly online

Order accessories

Request product

ecom-CL2 -
Perfect for HVAC professionals and service technicians

The ecom-CL2 is designed for inspections and short-term measurements on small combustion systems. In its ergonomic case, it delivers exact measurement results within seconds – from power-on to documentation. The operating logic is clearly structured, the display is easy to read and the measurement sensors are tailored to everyday requirements.

Options

Additional NO sensor

Direct contact.
Clear Solution

We provide personal support and develop tailored solutions for your needs.

We are happy to advise you

+49 2371 945-5

ecom GmbH
Am Großen Teich 2
D-58640 Iserlohn

Why choose ecom
devices?

Climate chamber calibration

The measurement accuracy of gas sensors (CO, NO, SO2) is determined and adjusted at 5, 20 and 40°C in the climate chamber using standardized test gases. In specially developed gas channels, overpressure and underpressure in the flue gas analyser are equalized.

Completely ready for measurement

ecom devices are delivered completely ready for measurement with probe, tubing and extensive connection accessories. Includes consumables for the initial period of use for an immediate start without additional effort.

CO overload protection

The automatic CO shutdown with integrated fresh air purging reliably protects the CO sensor from overload, even without interrupting other measurement parameters. This ensures precise results and a significantly longer sensor lifespan.

Additional sensor option

The ecom-CL2 can also be equipped with an NO sensor.

Electronic condensate monitoring

Electronic condensate monitoring detects accumulating condensate early and reliably protects the device from moisture. If the condensate volume is too high, the measurement is automatically shut down for maximum operational safety and consistently precise measurement results.

Easy operation

The intuitive menu navigation enables fast and safe operation from the very first use. Clear structures, logically designed menus and a user-friendly interface ensure efficient work without lengthy familiarization.

Wireless data transmission via WiFi or BLE

Wireless data transfer enables fast and reliable transmission of measurement data without additional cabling. With the free ecomMANDER App, devices can be conveniently controlled remotely and measurement values displayed in real-time on a smartphone or tablet. This provides greater flexibility in use and efficient processing of results.

Lightweight design & transport protection

The ultra-light aluminum housing ensures maximum mobility and high robustness in everyday work. Combined with the robust aluminum housing, the device is optimally protected and can be transported safely and comfortably at all times.

Integrated printer

The integrated printer allows for direct printing of measurement results on-site. This saves time, ensures complete documentation and eliminates the need for additional devices.

Get to know the ecom-CL2

Simple digital flue gas analysis

At ecom, we combine precise measurement technology with intelligent software. Digitalization in the trades requires solutions that are wireless, secure, and above all intuitive. With the ecomMANDER app, your smartphone becomes the central hub for all measurement data. From simple connection setup to live display of values and paperless documentation.

Learn More

Our service promise

Your measuring device is your most important tool – when it fails, it costs time, money and frustration. Thanks to the many years of experience of ecom’s internationally based customer service team, users worldwide benefit from first-class service, short processing times and measurement accuracy of the highest standard.

Learn More

Technical specifications

With O₂/CO longlife sensors
Automatic CO switch-off and purge (however, without interrupting the measurement)
Robust aluminum protective housing
With a sturdy carrying handle and a comfortable shoulder strap
Use as a wall-mounted flue gas measuring device:
rear magnets for attachment to metal surfaces
Use as a freestanding flue gas measuring device:
fold-out, non-slip support stand
Condensate trap incl. electronic condensate monitoring and fine dust filter
Integrated thermal high-speed printer with 58 mm wide, document-proof printer paper
Wireless data transmission (e.g., to a smartphone or tablet)
Integrated LiFePo4 high-performance battery, providing long device runtime
Complete with sampling probe and cone as well as 3-chamber tubing
T-room sensor with cable, fixing cone and mounting magnet
Storage of probe, tubing and sensor in the protective housing
Side charging with the protective housing closed via the supplied power adapter
Internal data memory – enabling the recording of the 300 most important measurements
Operating instructions and calibration certificate – issued after 100% sensor calibration in the climate chamber
ecom service package (incl. free PC software)

Dimensions with protective housing

Closed: 340 x 230 x 95 mm (W x H x D)
Fully unfolded: 340 x 350 x 180 mm (W x H x D)

Weight with protective housing

Approx. 3.0 kg (complete with probe and tubing)

Tested in accordance with EN 50379-2 and 1st BImSchV

Order directly online

Downloads & information

Technical data sheet ecom-CL2 (Flue gas analysis)

ecom-CL2 Flyer

Benefits in everyday practice

With the ecom-CL2, you get a measuring device that is compact yet fully equipped, with no compromises on quality or measurement performance. Whether for daily customer inspections, routine maintenance, or quick diagnostics, the combination of robust construction, integrated printer and smart data interface helps you work faster and more efficiently than ever before.
